Neural Network and Backpropagation 1 X1 X2 X3 X 784 𝝷 Let’s first use a Single Neuron to recognize handwritten digits 784 x 10 784 x 10 784 x 10 2 X1 X2 X3 X 784 1 30 2 1 10 3 Let’s use multiple neurons to recognize handwritten digits A neural network is put together by hooking together many of our simple “neurons,” so that the output of a neuron can be the input of another. input layer output layer hidden layer 2 X1 X2 X3 X 784 W1 784 x 30 1 30 2 1 10 3 W2 30 x 10 Define weights Let’s use multiple neurons to recognize handwritten digits input layer output layer hidden layer 2 X1 X2 X3 X 784 W1 784 x 30 1 30 2 1 10 3 W2 30 x 10 Let’s use multiple neurons to recognize handwritten digits Define biases b1 b2 b3 b30 b1 b2 b10 input layer output layer hidden layer Can you recall the bias term from Lecture 1 or 2? 2 X1 X2 X3 X 784 W1 784 x 30 1 30 2 1 10 3 W2 30 x 10 Let’s use multiple neurons to recognize handwritten digits Define weighted input b1 b2 b3 b30 b1 b2 b10 Z1 Z2 Zl = Wla l-1 +bl 10/02/2020 Ahsan Adeel - AI and ML Course (6CS012) 2 X1 X2 X3 X 784 W1 784 x 30 1 30 2 1 10 3 W2 30 x 10 Let’s use multiple neurons to recognize handwritten digits Define activations b1 b2 b3 b30 b1 b2 b10 Z1 Z2 Zl = Wla l-1 +bl a l = 𝞂( Zl ) a1 a2 a0 2 X1 X2 X3 X 784 W1 784 x 30 1 30 2 1 10 3 W2 30 x 10 Let’s use multiple neurons to recognize handwritten digits Forward propagation b1 b2 b3 b30 b1 b2 b10 Z1 Z2 Zl = Wla l-1 +bl a l = 𝞂( Zl ) a1 a2 a0 • A_0 =? • Z_1 =? • A_1 =? • Z_2 =? • A_2 =? • error = 2 X1 X2 X3 X 784 W1 784 x 30 1 30 2 1 10 3 W2 30 x 10 Let’s use multiple neurons to recognize handwritten digits Backpropagation b1 b2 b3 b30 b1 b2 b10 Z1 Z2 Zl = Wla l-1 +bl a l = 𝞂( Zl ) a1 a2 a0 Update: • W1? • b1? • W2? • b2 Backpropagation Update: • W1? • b1? • W2? • b2 W1= W1 - 𝞰𝞩 J(W1) b1= b1 - 𝞰𝞩 J(b1) W2= W2 - 𝞰𝞩 J(W2) b2= b2 - 𝞰𝞩 J(b2) Backpropagation Update: • W1? • b1? • W2? • b2 W1= W1 - 𝞰𝞩 J(W1) How to find these gradients now? b1= b1 - 𝞰𝞩 J(b1) W2= W2 -𝞰𝞩 J(W2) b2= b2 - 𝞰𝞩 J(b2) 2 X1 X2 X3 X 784 W1 784 x 30 1 30 2 1 10 3 W2 30 x 10 Let’s use multiple neurons to recognize handwritten digits b1 b2 b3 b30 b1 b2 b10 Z1 Z2 Zl = Wla l-1 +bl a l = 𝞂( Zl ) a1 a2 a0 Introduce an error function δ3 δ1 δ2 2 X1 X2 X3 X 784 W1 784 x 30 1 30 2 1 10 3 W2 30 x 10 Let’s use multiple neurons to recognize handwritten digits b1 b2 b3 b30 b1 b2 b10 Z1 Z2 Zl = Wla l-1 +bl a l = 𝞂( Zl ) a1 a2 a0 Introduce an error function δ3 = a2 - y δ δ2 1 Four BP equations σ(z) = 1/1+exp(−z) σ'(z) = σ(z) * (1- σ(z)) Introduce an error function Let’s call last as “layer L” and all others as “layers l” 2 X1 X2 X3 X 784 W1 784 x 30 1 30 2 1 10 3 W2 30 x 10 Let’s use multiple neurons to recognize handwritten digits b1 b2 b3 b30 b1 b2 b10 Z1 Z2 Zl = Wla l-1 +bl a l = 𝞂( Zl ) a1 a2 a0 δ3 = a2 - y δ δ2 1 δ1 = ? δ2 = ? δ3 = ? 𝞩 J(W1) = δ1 .a0T 𝞩 J(W2) = δ2 .a1T 𝞩 J(b1) = δ1 𝞩 J(b2) = δ2 W1 = W1 - 𝞰 𝞩 J(W1) W2 = W3 - 𝞰 𝞩 J(W2) b1 = b1 - 𝞰 𝞩 J(b1) b2 = b2 - 𝞰 𝞩 J(b2) Task 1 (MNIST classification using SGD driven ANN - Download WS6 folder from Canvas - Use the “MNIST_Data” from WS5 and store it in the same folder - The provided code will extract and pre-process the dataset - The provided code also does the post-processing including thresholding, accuracy etc. - For your ease, following lines are left empty for you to fill. # ForwardProp Z_0 = x A_0 = Z_0 Z_1 = A_1 = Z_2 = A_2 = error = # Backprop delta3 = delta_2 = d_W_2 = # derivative of 'J' w.r.t 'W2' d_b_2 = # derivative of 'J' w.r.t 'b2' delta_1 = d_W_1 = # derivative of 'J' w.r.t 'W1' d_b_1 = # derivative of 'J' w.r.t 'b1' W_1 = W_1 – eta *d_W_1 W_2 = W_2 – eta * d_W_2 b_1 = b_1 – eta *d_b_1 b_2 = b_2 – eta *d_b_2 # ForwardProp – Testing on a test data A_0 = x_t A_0 = np.reshape(Z_0, (784, 500)) Z_1 = A_1 = Z_2 = A_2 Task 1 (MNIST classification using SGD driven ANN 1.1. Explain in detail (step by step) the forward and backpropagation algorithm with equations 1.2. Complete the equations and run the code 1.3. Test the model on test data 1.4. Compare results with WS5 Task 2 1.5. Comment on results in detail References: • http://deeplearning.stanford.edu/tutorial • Huff, Trevor, and Scott C. Dulebohn. "Neuroanatomy, Visual Cortex." (2017). • Ian Goodfellow and Yoshua Bengio and Aaron Courville, Deep Learning, MIT Press, 2016, url: http://www.deeplearningbook.org • https://www.khanacademy.org/math/statistics-probabilit • 3blue1brown: https://www.3blue1brown.com/ • http://neuralnetworksanddeeplearning.com/index.html

Solution PreviewSolution Preview

These solutions may offer step-by-step problem-solving explanations or good writing examples that include modern styles of formatting and construction of bibliographies out of text citations and references. Students may use these solutions for personal skill-building and practice. Unethical use is strictly forbidden.

import mnist_loader
import numpy as np
import matplotlib.pyplot as plt
import scipy.sparse

import input_data

def oneHotIt(Y):
    m = Y.shape[0]
    #Y = Y[:,0]
    OHX = scipy.sparse.csr_matrix((np.ones(m), (Y, np.array(range(m)))))
    OHX = np.array(OHX.todense()).T
    return OHX


def sigmoid(z):
    """The sigmoid function."""
    return 1.0/(1.0+np.exp(-z))

def sigmoid_prime(z):
    """Derivative of the sigmoid function."""
    return sigmoid(z)*(1-sigmoid(z))

mnist = input_data.read_data_sets("MNIST_Data/", one_hot=False)
batch = mnist.train.next_batch(5000)

Y = batch[1]
X = batch[0]

#X = X / 255

y_new = np.zeros(Y.shape)
y_new[np.where(Y == 0.0)[0]] = 1
Y = y_new...
